| Air Interface | Technical Standard |
Compatible with SA、NAS、FDD-LTE,TDD-LTE, WCDMA 802.11 b/g/n/ac |
| Frequency |
NSA：n1/n2/n3/n5/n7/n8/n12/n20/n25/n28/n38/n40/n41/n48/n66/n71/ n77/n78/n79 SA：n1/n2/n3/n5/n7/n8/n12/n20/n25/n28/n38/n40/n41/n48/n66/n71/n77/n78/n79 FDD：B1/B2/B3/B4/B5/B7/B8/B12(B17)/B13/B14/B18/B19/B20/B25/B26/B28/B29/B30/B32/B66/B71 TDD：B34/B38/B39/B40/B41/B42/B43/B48 WCDMA：B1/B2/B3/B4/B5/B6/B8/B19 |
|
| WIFI | 2.4&5 GHz, WIFI 4T4R，802.11 a/b/g/n/ac | |
| Performance | Maximum Data Throughput |
SA：DL 2.1 Gbps; UL 450 Mbps NSA：DL 2.5 Gbps; UL 600/650 Mbps LTE：DL 1.0 Gbps; UL 200 Mbps WCDMA：DL 42 Mbps; UL 5.76 Mbps |
| Hardware | Receive Diversity | Support Receive Diversity |
| MIMO |
Support 4×4MIMO in DL direction，Output Max Power：21~23dBm，External Antenna 6dBi(optional) |
|
| BB Chipset | Qualcomm X55 / UNISOC UDX710 | |
| AP+WIFI Chipset | MT7621DAT+MT7603E+MT7613BEN | |
| Memory | RAM:128Mb , ROM:1024Mb | |
| power consumption | <15W | |
| Power Voltage | DC12V/2A | |
| USIM/SIM |
2FF SIM card support SIM/USIM/UIM,standard 6 PIN SIM card interface, support 3V SIM card and 1.8V SIM card;internal push-push SIM slot |
|
| LED | SYS, LTE, SIGNAL, WiFi, WAN,LAN,SIM | |
| USB | 1 USB 2.0 port support Share | |
| Antenna |
2 x LTE 2x2 MiMo 2 x WIFI (2.4 + 5G) 4*4 MIMO Output Power 19dBm ， Antenna （3dBi） |
|
| Buttons | POWER，Reset | |
| Ethernet | 4 LAN ports or 1WAN+3LAN, 10BaseT/100Base/1000Base automatic adaptive port | |
| Reset | Pin hole | |
| ESD | ESD Protection circuit；Contact±4KV、Air±8KV |
