Hardware Characteristic
Support Button
Power Button:
On/Off, power on the MiFi after press 3 seconds; power off the MiFi after press 3 seconds;
WPS Button:
On/Off, enable/disable the WPS function of Wi-Fi after press 3 seconds;
Software Reset Button:
Reload to default settings after press 6 seconds;
Memory
4Gbits ROM + 2Gbits RAM
LED Indicator
Power/Battery Status Indicator (2 Colors, Red, Blue)
Red light flash for battery capacity lower than 10%
Red light active for battery capacity 10%~30%
Purple light active for battery capacity 30%~90%
Blue light active for battery capacity larger than 90%
Blue light flash for charging
3G/4G Signal Indication (3 Colors, Red, Green, Blue)
Green light active for 3G/4G network registered
Blue light flash for 3G/4G data connection
Red light active for 3G/4G network not registered
Wi-Fi Status Indicator(1 Color, Blue)
Blue light active for Wi-Fi enabled
Blue light flash quickly for the WPS function is enabled
Off for Wi-Fi disabled
New SMS Indicator(1 Color, Blue)
Blue light active for new SMS indicator
Off for no new SMS
SIM Card Slot
One SIM Card Slot, NANO(4FF) SIM
USB Port
Type-C USB 2.0 interface
Battery
Type: Li-ion Polymer Battery
Capacity: 2700mAh
Endurance: 7-9 hours (normal network situation)
WWAN
3GPP Release
LTE-A Release 12
Bands Supported
LTE Bands: B1/B3/B5/B7/B8/B18/B19/B20/B26/B28/B32/B38/B40/B41/B42/B43
LTE Bandwidth: 1.4/3/5/10/15/20/40(2CA) MHz
MIMO: 2x2 DL MIMO, 1x1 UL MIMO
Carrier Aggregatioin: DL 2CC, UL 1CC
2CA:
B1+B1/3/5/7/8/18/19/20/26/28/32/38/40/41/42
B3+83/5/7/8/19/20/26/28/38/40/41/42
B5+B5/7/30/38/40/41
B7+B7/8/20/28/32/42
B8+B8/32/38/40/41/42
B20+B32/40/42
B28+832/38/40/41/42
B38+B38
B40+B40/42
B41+B41/42
B42+819/42
UMTS Bands: B1/3/5/6/8Wireless Mini Pocket Router - Product Specification
TSD-23070501 - R02
Product Specification
Page 6 of 9
Modulation: QPSK/16-QAM/64-QAM/256-QAM
Data Rate
LTE Cat.6 DL 2x2MIMO + 2CC +256QAM (300Mbps); UL 50Mbps
DC-HSPA+ (DL) data service of up to 42.2 Mbps
HSPA+ (DL) data service of up to 21.1 Mbps
HSDPA (DL) data service of up to 14.4 Mbps
HSUPA (UL) data service of up to 5.76 Mbps
UMTS data service of up to 384 kbps
Tx Power
Class 3 (23+1/-1dBm) for LTE bands
Class 3 (24+1/-3dBm) for UMTS bands
Antenna
4 x Internal 3G/4G antenna
WLAN
Standard
IEEE 802.11 a/b/g/n/ac
Output Power
15dBm 802.11b @2.4GHz
11dBm 802.11g @2.4GHz
10dBm 802.11n @2.4GHz
11dBm 802.11a @5GHz
11dBm 802.11n @5GHz
11dBm 802.11ac @5GHz
Sensitivity
802.11a: RX sensitivity < -65dBm at 65Mbps
802.11b: RX sensitivity < -82dBm at 11Mbps
802.11g: RX sensitivity < -70dBm at 54Mbps
802.11n: RX sensitivity < -64dBm at HT20 MCS7
802.11n: RX sensitivity < -61dBm at HT40 MCS7
802.11ac: RX sensitivity < -64dBm at HT20 MCS7
802.11ac: RX sensitivity < -61dBm at HT40 MCS7
802.11ac: RX sensitivity < -58dBm at HT80 MCS7
Data Rate
6/9/11/12/18/24/36/48/54Mbps in 802.11a mode
1/2/5.5/11Mbps in 802.11b mode
6/9/11/12/18/24/36/48/54Mbps in 802.11g mode
300Mbps in 802.11n mode
866Mbps in 802.11ac mode
Frequency
2.4~2.483GHz, 5.8GHz
Modulation
802.11a: OFDM
802.11b: BPSK/QPSK/CCK
802.11g: BPSK/QPSK/16-QAM/64-QAM
802.11n: BPSK/QPSK/16-QAM/64-QAM (2x2 MIMO)
802.11ac: 256QAM MIMO-OFDM (2x2 MIMO)
Access Mode
CSMA/CA
Number of Channels America/FCC: (1-11 Channels, 2.4GHz)
Europe/ETSI: (1-13 Channels, 2.4GHz)
36-165 Channels, 5.8GHz
Antenna
2 x Internal Wi-Fi Antenna
