support Cat6/Cat12 Support f FDD-LTE, TDD-LTE and WCDMA.
The maximum downlink rate in CA mode can reach to 600 Mbps, the maximum uplink rate reach to 150 Mbps.
WiFi support dual frequency concurrency, the 2.4G+5.8G rate is 1300Mbps
support VoLTE and VoIP
|
Table1 .Band |
|||
|
Item |
A391-EAU-30 (CAT6) |
A39-EAU-00 (CAT12) |
A391-EAU-10 (CAT13) |
|
WCDMA |
Band 1/3/5/8 |
Band 1/3/5/6/8/19 |
Band 1/3/5/6/8/19 |
|
FDD-LTE |
Band 1/3/5/7/8/18/19/20/28/32 |
Band 1/3/5/7/8/18/19/20/28/32 |
Band 1/3/5/7/8/18/19/20/28/32 |
|
TDD-LTE |
Band38/40/41（2535Mhz-2655Mhz） 42/43/48 |
Band38/40/41（2535Mhz~2655Mhz）/ 42/43/48 |
Band38/40/41（2535Mhz~2655Mhz）/ 42/43/48 |
|
Tablee 2.DATA RATE |
|||
|
Item |
A391-EAU-30 (CAT6) |
A391-EAU-30 (CAT12) |
A391-EAU-30 (CAT13) |
|
WCDMA |
Downlink peak rate 42Mbps |
Downlink peak rate 42Mbps |
Downlink peak rate 42Mbps |
|
Uplink peak rate 5.76Mbps |
Uplink peak rate 5.76Mbps |
Uplink peak rate 5.76Mbps |
|
|
LTE |
Downlink peak rate 300Mbps |
Downlinkpeak rate 600Mbps |
Downlinkpeak rate 400Mbps |
|
Uplink peak rate 50Mbps |
Uplink peak rate150Mbps |
Uplink peak rate150Mbps |
|
|
Downlink 4 x 4 MIMO |
Downlink 4 x 4 MIMO |
Downlink 2 x 2 MIMO |
|
|
3.Cellular |
|||
|
Item |
A391-EAU-30 (CAT6) |
A391-EAU-00 (CAT12) |
A391-EAU-10 (CAT13) |
|
WCDMA |
• 3GPP R9/DC-HSDPA/HSPA+/ HSDPA/HSUPA/WCDMA |
•3GPP R9/DC-HSDPA/HSPA+/ HSDPA/HSUPA/WCDMA |
•3GPP R9/DC-HSDPA/HSPA+/ HSDPA/HSUPA/WCDMA |
|
LTE |
•3GPP R12 • Support 2DLCA • Support downlink 64QAM、16QAM、QPSK • Support uplink 16QAM、QPSK •Support RF bandwidth1.4MHz~20MHz |
• 3GPP R12 • Support 3DLCA、2ULCA • Support downlink 256QAM、64QAM、 16QAM、QPSK • Support uplink64QAM、16QAM、QPSK • Support RF bandwidth 1.4MHz~20MHz |
• 3GPP R12 • Support 3DLCA、2ULCA • Support downlink 256QAM、64QAM、 16QAM、QPSK • Support uplink64QAM、16QAM、QPSK • Support RF bandwidth 1.4MHz~20MHz |
|
Table 4.other features |
||
|
item |
Description |
|
|
IC |
SDX12 |
|
|
SDRAM |
2Gb LPDDR2 + 2Gb NAND Flash |
|
|
OS Compatibility |
Linux/Android/Windows |
|
|
Power level |
Class 3 (23.5dBm ± 2dB) for WCDMA bands |
|
|
Class 3 (23dBm ± 2dB) for LTE bands |
||
|
wifi |
802.11 b/g/n/ac 2.4G+5.8G (1300Mbps) |
|
|
Ethernet port |
RJ45 x 4, LAN 10/100/1000 aotu-sensing |
|
|
Voice chipset |
LE9643 |
|
|
Adapter |
DC Power 12V/1A |
|
|
SIM slot |
1.8v/3.3V USIM |
|
|
button |
|
|
|
size |
|
|
|
weight |
|
|
|
Table 5.Carrier Aggregation |
|
|
item |
A391-EAU |
|
2CA-DL |
1A-1A/3A/5A/7A/8A/18A/19A/20A/28A/32A/ 38A/40A/41A/42A 3A-3A/5A/7A/8A/20A/28A/32A/38A/40A/41A/42A 5A-7A 7A-7A/8A/20A/28A/32A 8A-40A 20A-32A 28A-40A 40A-40A 41A-41A/42A 1C 3C 5B 7C 38C 40C 41C 42C |
|
2CA-UL |
3C 5B 7C 38C 40C 42C |
|
3CA-DL |
1A-3A-5A/7A/8A/19A/20A/28A/32A/38A/40A/ 41A/42A 1A-5A-7A 1A-7A-8A/20A/28A 1A-20A-32A 1A-41A-42A 1A-7C/41C/42C 3A-3A-7A/20A 3A-5A-7A 3A-7A-7A/8A/20A/28A 3A-8A-38A 3A-28A-40A 3A-7C/40C/41C/42C 7A-20A-32A 19A-42C 28A-40C 41A-41C/42C 3C-5A/7A/8A/20A/28A/41A 7C-28A 41C-42A 40D 41D |
|
Table 6. wifi |
|
|
standard |
IEEE 802. 11 b/g/n/ac |
|
Channel bandwidth |
20MHz,40MHz,80MHz |
|
frequent |
2.4G/5.8G |
|
txrx |
2T2R |
|
mimo |
DL 2 x 2 MIMO |
|
rate |
2.4g + 5.8G (1300Mbps) |
|
antenna type |
Internal Antenna |
|
antenna gain |
1.5~2dBi |
|
active user |
64 Users |
2. Software
|
TABLE 7. SOFTWARE |
|
|
language |
English ,Chinese or others |
|
IP Protocol |
IPV4/IPV6 |
|
SIM MANAGEMENT |
Pin code management, SIM card lock, SIM card unplug/plug |
|
Interet acces |
Automatic/Manual |
|
LTE scan mode |
Full band scan, Frequency Lock |
|
WLan |
Configuration,WPS |
|
vpn |
L2TP,PPTP |
|
NAT |
Port forwarding DMZ |
|
Firewall |
IP/MAC/URL Filter Access Control TCP port scan Death of Ping |
|
Network management |
TR069 |
|
dIAGNOSTICS |
TCP Dump Trace route |
|
STATISICS |
LTE Status Connection Status System Up Device Status DHCP Client List WIFI Status Firewall Status |
|
maintenance |
Date & Time setting Restore factory settings Restore / Back up configuration file Firmware upgrade locally/OTA (over the air) |
|
